Cabrestante hidráulico fueraborda LD50-173

1 / 2

Actuador hidroeléctrico

Cabrestante hidráulico fueraborda LD50-173

Cabrestante hidráulico fueraborda LD50-173 is supplied by Elerover as a actuador hidroeléctrico for OEM and industrial motion projects. Request OEM customization for voltage, stroke, feedback and connectors.

Manufactured and supplied by Elerover — Actuador hidroeléctrico manufacturer and OEM partner for industrial, medical, furniture and solar motion systems.

Parámetros clave

10
Operating temperature
11
N.W/G.W/Packing size
No
Item
Request OEM Quote WhatsApp
  • Custom stroke
  • Custom voltage
  • Custom connector
  • OEM / private-label inquiry

Descripción general del producto

No Item Data 1 Voltage DC12v/24v/48v 2 Power 300w 3 Telescopic stroke 173mm 4 Maximum lift 1.8T 5 Collision Protection Yes 6 Lifting speed 10-11mm/s 7 waterproof level IPX6 8 Noise level 75DB 9 Working condition oudoor 10 Operating temperature -30 degrees Celsius to 70 degrees Celsius 11 N.W/G.W/Packing size 5.8kg/6.1kg/61x20x13cm

Características clave

  • Reliable Electric Hydraulic Actuator solution for OEM projects
  • Robust mechanical design for continuous duty
  • Flexible voltage and mounting options
  • Custom configurations available on request

Especificaciones técnicas

1 Voltage
2 Power
3 Telescopic stroke
4 Maximum lift
5 Collision Protection
6 Lifting speed
7 waterproof level
8 Noise level
9 Working condition
10 Operating temperature
11 N.W/G.W/Packing size
No Item

Aplicaciones

  • Elevación

Detalles adicionales

Electric Hydraulic Actuator

Outboard Hydraulic Warper LD50-173

No Item Data 1 Voltage DC12v/24v/48v 2 Power 300w 3 Telescopic stroke 173mm 4 Maximum lift 1.8T 5 Collision Protection Yes 6 Lifting speed 10-11mm/s 7 waterproof level IPX6 8 Noise level 75DB 9 Working condition oudoor 10 Operating temperature -30 degrees Celsius to 70 degrees Celsius 11 N.W/G.W/Packing size 5.8kg/6.1kg/61x20x13cm

Need a Custom Configuration?

Contact Elerover for voltage, stroke, speed, feedback, cable length and connector customization. Messages go to [email protected].

Installation Guidance

Mount on a rigid structure, avoid side load, and confirm electrical polarity before first motion. Protect cables from abrasion and leave service access for inspection.
