SLA01-WP vérin linéaire IP68

1 / 4

Vérin linéaire

SLA01-WP vérin linéaire IP68

Vérin linéaire électrique usage intensif : alliage d’aluminium, poussée/traction jusqu’à 1200N. Conception silencieuse, bruit réduit...

Manufactured and supplied by Elerover — Vérin linéaire manufacturer and OEM partner for industrial, medical, furniture and solar motion systems.

Paramètres clés

Model
SLA01-WP
Working Voltage
12V / 24V / 36V / 48V DC
Stroke
10–1000mm (custom)
Protection Class
IP69
Max Speed
Up to 80mm/s
Limit Switch
Built-in
Feedback
Potentiometer (10K / 5K) or encoder (optional)
Duty Focus
Outdoor / wash-down OEM motion
Request OEM Quote WhatsApp
  • Custom stroke
  • Custom voltage
  • Custom connector
  • OEM / private-label inquiry

Aperçu du produit

The SLA01-WP is a compact IP69 waterproof electric linear actuator with a parallel-motor layout. It offers custom stroke from 10–1000mm, speeds up to 80mm/s and force options up to the 1200N class for doors, windows, trapdoors, solar tracking, medical equipment and outdoor OEM automation.

Caractéristiques clés

  • IP69 waterproof rating with rubber cover accessory
  • Compact parallel-motor design
  • Stroke 10–1000mm custom; L = S + 105mm
  • Speed / load options from 50N@80mm/s to 900N@5mm/s
  • 12V / 24V / 36V / 48V DC
  • Built-in limit switches; optional potentiometer or encoder
  • Low noise, maintenance-free sealed construction

Spécifications techniques

Model SLA01-WP
Working Voltage 12V / 24V / 36V / 48V DC
Stroke 10–1000mm (custom)
Max Speed Up to 80mm/s
Max Dynamic Load Up to 1200N class
Protection Class IP69
Install Length L = S + 105mm (retracted)
Mounting Holes 2 × Ø6.4mm
Limit Switch Built-in
Feedback Potentiometer (10K / 5K) or encoder (optional)
Cable Length 1m standard (custom available)
Rated Power About 30W
Duty Focus Outdoor / wash-down OEM motion

Applications

  • Suivi solaire
  • Agriculture
  • Levage

FAQ

Qu’est-ce que le SLA01-WP ?

Vérin linéaire électrique usage intensif : alliage d’aluminium, poussée/traction jusqu’à 1200N. Conception silencieuse, bruit réduit...

Elerover fabrique-t-il le SLA01-WP ?

Oui. Elerover est fabricant et fournisseur de vérin linéaire. Ce modèle propose des options OEM indiquées dans les données produit — indiquez le cycle de service et la quantité pour un devis usine.

Quelles sont les spécifications clés du SLA01-WP ?

Les valeurs issues des spécifications produit incluent tension 12V / 24V / 36V / 48V DC, charge 1200N, course 10–1000mm (custom), protection IP69. Consultez le tableau Spécifications techniques sur cette page.

Pour quelles applications le SLA01-WP est-il prévu ?

Applications typiques : Suivi solaire, Agriculture, Levage.

Comment demander un devis pour le SLA01-WP ?

Indiquez charge, course, tension, indice IP, cycle de service, quantité et options OEM via le formulaire de contact ou WhatsApp.

Détails supplémentaires

Waterproof Linear Actuator

12V 24V SLA01-WP IP69 waterproof linear actuator for doors, windows and outdoor OEM motion

Compact parallel-motor electric linear actuator with IP69 sealing, up to 1200N class force options, speeds up to 80mm/s, and custom stroke from 10–1000mm for outdoor and wet-duty automation.

Model
SLA01-WP
Max Load
Up to 1200N
Max Speed
80mm/s
Voltage
12 / 24 / 36 / 48V DC
Stroke
10–1000mm
Protection
IP69

Stroke Options

Multiple stroke lengths share the same motor / gearbox package. Choose the stroke that matches your travel; overall retracted length follows L = S + 105mm.

SLA01-WP waterproof linear actuator stroke length options

External Dimensions

Dimensional drawing for the SLA01-WP. Mounting hole diameter is Ø6.4mm at both ends. Retracted center-to-center length L = stroke (S) + 105mm.

SLA01-WP waterproof linear actuator dimensions drawing

  • Overall envelope (end view): about 42mm wide × 81.3mm high
  • Motor tube Ø38mm; actuator tube about Ø33.8mm
  • Center distance between motor and tube axes: 37mm
  • Mounting holes: 2 × Ø6.4mm
  • Install length: L = S + 105mm (retracted)

Speed vs Load

Select the gear / screw option that matches your duty. Speeds are typical values at the stated load from the SLA01-WP catalogue.

Code Gear Ratio Screw Speed / Load Full-load Current @12V @24V @36V @48V IP
A30:1ACME5mm/s / 900N2.3A2.1A1.6A1.2AIP69
B30:1ACME13mm/s / 700N2.3A2.1A1.5A1.2AIP69
C30:1ACME15mm/s / 600N2.1A1.7A1.5A1.0AIP69
D20:1ACME20mm/s / 400N1.8A1.6A1.4A1.0AIP69
E20:1ACME26mm/s / 300N1.8A1.6A1.3A1.0AIP69
F10:1ACME40mm/s / 100N1.5A1.4A1.3A1.0AIP69
G10:1ACME80mm/s / 50N1.5A1.4A1.2A1.0AIP69

Notes: Actual speed decreases as load increases. Confirm push/pull direction, duty cycle and power supply sizing before ordering. Custom stroke, cable length and feedback options are available.

SLA01-WP waterproof linear actuator catalogue specification sheet

Need a Custom Configuration?

Contact Elerover for stroke, force/speed code, voltage, feedback, cable length and bracket options. Messages go to [email protected].
