SLA-PT01 vérin linéaire pour canapé

1 / 5

Vérin linéaire

SLA-PT01 vérin linéaire pour canapé

SLA-PT01 vérin linéaire pour canapé is supplied by Elerover as a vérin linéaire for OEM and industrial motion projects. Request OEM customization for voltage, stroke, feedback and connectors.

Manufactured and supplied by Elerover — Vérin linéaire manufacturer and OEM partner for industrial, medical, furniture and solar motion systems.

Paramètres clés

A Power
58W Load
inch Stroke
Approx. 230±2mm/9.1±0.08inch No-load Speed
Applications
Perfectly suited for electric beds, electric sofas, and other furniture that req
N (Push) Speed
34mm/s Motor Speed
RPM Minimum Installation Distance
Approx. 127±2mm/5.0±0.08inch Maximum Installation Distance
Request OEM Quote WhatsApp
  • Custom stroke
  • Custom voltage
  • Custom connector
  • OEM / private-label inquiry

Aperçu du produit

High-Performance Electric Recliner Actuator Motor Discover the ultimate in comfort and functionality with our high-performance electric recliner actuator motor, designed to meet the demands of modern furniture applications such as electric beds and electric sofas. Engineered with precision, this small yet powerful actuator offers a range of features to enhance your furniture’s performance and longevity. Features: Excellent Performance : Our small electric actuator boasts a short installation distance, compact size, and low noise, making it perfect for space-saving applications. Adjustable Switch : The actuator is equipped with an adjustable limited-cam type switch, allowing users to freely adjust the stroke to suit their specific needs. Big Thrust : Known for its impressive thrust and high-speed operation, this actuator comes with a high IP protection level, ensuring durability and reliability. Advanced Shell Design : Featuring a cutting-edge shell design, this actuator ensures high capacity, shockproof performance, low noise, and a long service life. Wide Applicability : Ideal for use in electric beds, electric sofas, and other furniture requiring vertical movement, providing seamless up and down adjustments. How to Use: Secure the push rod using the fixed buckle bolt. Connect the 01 connector power supply to activate the actuator. Product Specifications: Item Type : Electric Recliner Actuator Motor Material : PVC + Aluminum Alloy + Stainless Steel Total Weight : Approx. 1754g/61.9oz Voltage : DC 12V/24V/29V Current : 2.2A ~ 2A Power : 58W Load : 1000N (Push) Speed : 34mm/s Motor Speed : 3700 RPM Minimum Installation Distance : Approx. 127±2mm/5.0±0.08inch Maximum Installation Distance : Approx. 357±2mm/14.1±0.08inch Stroke : Approx. 230±2mm/9.1±0.08inch No-load Speed : 1.0 ± 0.4 inches (25 ± 10%) Applications: Perfectly suited for electric beds, electric sofas, and other furniture that requires smooth and efficient vertical movement. Enhance your living expe

Caractéristiques clés

  • Excellentes performances : faible encombrement, taille compacte et faible bruit.
  • Interrupteur réglable : fin de course à came réglable pour ajuster la course.
  • Forte poussée : poussée élevée, vitesse rapide et indice IP élevé.
  • Conception avancée du boîtier : haute capacité, antichoc, faible bruit, longue durée de vie.
  • Large applicabilité : lits électriques, canapés électriques et mobilier à mouvement vertical.
  • Fixer la tige de poussée avec le boulon de fixation.
  • Connecter l’alimentation du connecteur 01 pour activer le vérin.
  • Type d’article : moteur-actionneur de fauteuil électrique
  • Matériau : PVC + alliage d’aluminium + acier inoxydable
  • Poids total : env. 1754g/61,9oz
  • Tension : DC 12V/24V/29V
  • Courant : 2,2A ~ 2A

Spécifications techniques

s performance and longevity. Features Excellent Performance
a long service life. Wide Applicability Ideal for use in electric beds, electric sofas, and other furniture requiring ve
Approx. 1754g/61.9oz Voltage DC 12V/24V/29V Current
A Power 58W Load
N (Push) Speed 34mm/s Motor Speed
RPM Minimum Installation Distance Approx. 127±2mm/5.0±0.08inch Maximum Installation Distance
inch Stroke Approx. 230±2mm/9.1±0.08inch No-load Speed
Applications Perfectly suited for electric beds, electric sofas, and other furniture that req

Applications

  • Mobilier

FAQ

Qu’est-ce que le SLA-PT01 ?

Type d’article : moteur-actionneur de fauteuil électrique. Matériau : PVC + alliage d’aluminium + acier inoxydable. Poids total : env. 1754g/61,9oz. Tension : DC 12V/24V/...

Elerover fabrique-t-il le SLA-PT01 ?

Oui. Elerover est fabricant et fournisseur de vérin linéaire. Indiquez votre application et la quantité pour un devis usine sur ce modèle.

Quelles sont les caractéristiques clés du SLA-PT01 ?

Excellentes performances : faible encombrement, taille compacte et faible bruit. ; Interrupteur réglable : fin de course à came réglable pour ajuster la course. ; Forte poussée : poussée élevée, vitesse rapide et indice IP élevé.. Voir Caractéristiques clés sur cette page.

Pour quelles applications le SLA-PT01 est-il prévu ?

Applications typiques : Mobilier.

Comment demander un devis pour le SLA-PT01 ?

Indiquez charge, course, tension, indice IP, cycle de service et quantité via le formulaire de contact ou WhatsApp.

Détails supplémentaires

High-Performance Electric Recliner Actuator Motor

Discover the ultimate in comfort and functionality with our high-performance electric recliner actuator motor, designed to meet the demands of modern furniture applications such as electric beds and electric sofas. Engineered with precision, this small yet powerful actuator offers a range of features to enhance your furniture’s performance and longevity.

  1. Excellent Performance: Our small electric actuator boasts a short installation distance, compact size, and low noise, making it perfect for space-saving applications.
  2. Adjustable Switch: The actuator is equipped with an adjustable limited-cam type switch, allowing users to freely adjust the stroke to suit their specific needs.
  3. Big Thrust: Known for its impressive thrust and high-speed operation, this actuator comes with a high IP protection level, ensuring durability and reliability.
  4. Advanced Shell Design: Featuring a cutting-edge shell design, this actuator ensures high capacity, shockproof performance, low noise, and a long service life.
  5. Wide Applicability: Ideal for use in electric beds, electric sofas, and other furniture requiring vertical movement, providing seamless up and down adjustments.

How to Use:

  1. Secure the push rod using the fixed buckle bolt.
  2. Connect the 01 connector power supply to activate the actuator.
  • Item Type: Electric Recliner Actuator Motor
  • Material: PVC + Aluminum Alloy + Stainless Steel
  • Total Weight: Approx. 1754g/61.9oz
  • Voltage: DC 12V/24V/29V
  • Current: 2.2A ~ 2A
  • Power: 58W
  • Load: 1000N (Push)
  • Speed: 34mm/s
  • Motor Speed: 3700 RPM
  • Minimum Installation Distance: Approx. 127±2mm/5.0±0.08inch
  • Maximum Installation Distance: Approx. 357±2mm/14.1±0.08inch
  • Stroke: Approx. 230±2mm/9.1±0.08inch
  • No-load Speed: 1.0 ± 0.4 inches (25 ± 10%)

Perfectly suited for electric beds, electric sofas, and other furniture that requires smooth and efficient vertical movement. Enhance your living experience with the reliability and performance of our electric recliner actuator motor.

Upgrade your furniture today with our high-performance electric recliner actuator motor and experience the perfect blend of comfort, efficiency, and durability.
