Actuador lineal
SLA08B 7,000 N actuador lineal
SLA08B 7000N linear actuator from Elerover.
Especificaciones clave
- Carga máxima
- 7000 N
- Carrera
- 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa
- Velocidad
- 5.5 mm/s – 35.0 mm/s
- Tensión
- 12 V / 24 V / 36 V / 48 V DC
Descripción del producto
SLA08B 7000N linear actuator from Elerover. This DC linear actuator is built for OEM equipment that needs repeatable push/pull motion under industrial duty.
- Carga máxima
- 7000 N
- Carrera
- 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa
- Velocidad
- 5.5 mm/s – 35.0 mm/s
- Tensión
- 12 V / 24 V / 36 V / 48 V DC
- Grado IP
- IP65
- Ciclo de trabajo
- 25% (4 min continuous moving) IP Rat
Aplicaciones
- Construction
- Wheelchair
Especificaciones técnicas
| Carga máxima | 7000 N |
|---|---|
| Carrera | 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa |
| Velocidad | 5.5 mm/s – 35.0 mm/s |
| Tensión | 12 V / 24 V / 36 V / 48 V DC |
| Grado IP | IP65 |
| Ciclo de trabajo | 25% (4 min continuous moving) IP Rat |
Performance matrix
| No-load speed | Full-load speed | Thrust | Self-locking force |
|---|---|---|---|
| 5.5 mm/s | 4.0 mm/s | 7000 N | 10000 N |
| 8.5 mm/s | 7.0 mm/s | 7000 N | 10000 N |
| 11.0 mm/s | 9.5 mm/s | 5000 N | 8000 N |
| 17.0 mm/s | 14.0 mm/s | 4000 N | 7000 N |
| 22.0 mm/s | 18.0 mm/s | 3000 N | 5000 N |
| 35.0 mm/s | 28.5 mm/s | 2000 N | 4000 N |
Solicitar documentos técnicos
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
Quote context
