Schwenkantrieb
Modell SVH7-71-60-RC-24H30100
SVH7 7-Inch Dual Axis Slewing Drive | 24 V DC Solar Tracker Worm Gear Rotary Actuator
SVH7 7-Inch Dual Axis Slewing Drive | 24VDC Solar Tracker Worm Gear Rotary Actuator from Elerover.
Kernspezifikationen
- Abtriebsmoment
- Horizontal: 937 N·m; Elevation: 2100 N·m
- Haltemoment
- Horizontal: 10.4 kN·m; Elevation: 42 kN·m
- Kippmoment
- Horizontal: 13.5 kN·m; Elevation: 10 kN·m
- Übersetzung
- Horizontal: 71:1; Elevation: 60:1
Produktübersicht
SVH7 7-Inch Dual Axis Slewing Drive | 24VDC Solar Tracker Worm Gear Rotary Actuator from Elerover. This slewing drive provides controlled rotary torque for tracking, positioning and heavy rotary platforms.
- Abtriebsmoment
- Horizontal: 937 N·m; Elevation: 2100 N·m
- Haltemoment
- Horizontal: 10.4 kN·m; Elevation: 42 kN·m
- Kippmoment
- Horizontal: 13.5 kN·m; Elevation: 10 kN·m
- Übersetzung
- Horizontal: 71:1; Elevation: 60:1
- Spiel
- ≤ 0.17°
Anwendungen
- Dual-axis solar trackers
- PV / CPV / CSP tracking systems
- Antenna and satellite positioning
- Industrial rotary platforms
- Heavy sensor and camera gimbals
Vorteile
- 7-inch dual-axis slewing drive for azimuth and elevation motion
- Elevation output torque 2100 N·m / holding torque 42 kN·m
- Horizontal output torque 937 N·m / holding torque 10.4 kN·m
- Gear ratios 71:1 (horizontal) and 60:1 (elevation)
- Precision ≤ 0.17° on both axes
- 24VDC IP65 motors with hall A/B feedback
Technische Spezifikationen
| Drive type | 7-inch dual-axis electric slewing drive |
|---|---|
| Abtriebsmoment | Horizontal: 937 N·m; Elevation: 2100 N·m |
| Haltemoment | Horizontal: 10.4 kN·m; Elevation: 42 kN·m |
| Kippmoment | Horizontal: 13.5 kN·m; Elevation: 10 kN·m |
| Übersetzung | Horizontal: 71:1; Elevation: 60:1 |
| Spiel | ≤ 0.17° |
| Motorspannung | 24 V DC |
| IP-Schutzart | IP65 |
Configuration options
| Parameter | Horizontal Axis | Elevation Axis |
|---|---|---|
| Rated Output Speed | 0.042 rpm | 0.05 rpm |
| Rated Output Torque | 937 N·m | 2100 N·m |
| Tilting Moment | 13.5 kN·m | 10 kN·m |
| Holding Torque | 10.4 kN·m | 42 kN·m |
| Static Axial Rating | 133 kN | 110 kN |
| Static Radial Rating | 53 kN | 60 kN |
| Gear Ratio | 71:1 | 60:1 |
| Precision | ≤ 0.17° | ≤ 0.17° |
| Operating Temperature | -30°C ~ +60°C | -30°C ~ +60°C |
Configuration options
| Parameter | Horizontal Motor | Elevation Motor |
|---|---|---|
| Motor Code | 24H/30/15 (family) | 24H/30/100 |
| Rated Torque | 33 N·m | 100 N·m |
| Rated Speed | 3 rpm | 3 rpm |
| Motor Gear Ratio | High-ratio planetary | 236:1 |
| IP Class | IP65 | IP65 |
| Rated Current | < 1.9 A | Approx. 4.5 A |
| Motor Temp. Range | -40°C ~ +80°C | -40°C ~ +80°C |
Technische Dokumente anfordern
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
Quote context
