Schwenkantrieb
Modell SC5-62B-12RC
SC5 5-Inch Slewing Drive | 12 V DC Compact Worm Gear Rotary Actuator for Solar Tracker
SC5 5-Inch Slewing Drive | 12VDC Compact Worm Gear Rotary Actuator for Solar Tracker from Elerover.
Kernspezifikationen
- Abtriebsmoment
- 720 N·m / 531.4 lbf·ft
- Haltemoment
- 5450 N·m / 4022 lbf·ft
- Kippmoment
- 3160 N·m / 2322 lbf·ft
- Axiallast
- 52 kN / 11700 lbf
Produktübersicht
SC5 5-Inch Slewing Drive | 12VDC Compact Worm Gear Rotary Actuator for Solar Tracker from Elerover. This slewing drive provides controlled rotary torque for tracking, positioning and heavy rotary platforms.
- Abtriebsmoment
- 720 N·m / 531.4 lbf·ft
- Haltemoment
- 5450 N·m / 4022 lbf·ft
- Kippmoment
- 3160 N·m / 2322 lbf·ft
- Axiallast
- 52 kN / 11700 lbf
- Radiallast
- 28 kN / 6300 lbf
- Übersetzung
- 62:1
Anwendungen
- Solar trackers
- PV tracking systems
- Antenna positioning
- Industrial rotary actuation
- Light machinery and OEM platforms
Vorteile
- Compact 5-inch worm-gear slewing drive
- Output torque 720 N·m / holding torque 5450 N·m
- Tilting moment 3160 N·m
- Gear ratio 62:1 with precision ≤ 0.17°
- Rated output speed under 3 rpm
- 12VDC motor interface family (12RC)
Technische Spezifikationen
| Drive type | 5-inch electric worm-gear slewing drive |
|---|---|
| Abtriebsmoment | 720 N·m / 531.4 lbf·ft |
| Haltemoment | 5450 N·m / 4022 lbf·ft |
| Kippmoment | 3160 N·m / 2322 lbf·ft |
| Axiallast | 52 kN / 11700 lbf |
| Radiallast | 28 kN / 6300 lbf |
| Übersetzung | 62:1 |
| Spiel | ≤ 0.17° |
| Motorspannung | 12 V DC |
Configuration options
| Parameter | Metric Value | Imperial Value |
|---|---|---|
| Rated Output Speed | < 3 rpm | — |
| Output Torque | 720 N·m | 531.4 lbf·ft |
| Tilting Moment | 3160 N·m | 2322 lbf·ft |
| Holding Torque | 5450 N·m | 4022 lbf·ft |
| Static Axial Rating | 52 kN | 11700 lbf |
| Static Radial Rating | 28 kN | 6300 lbf |
| Dynamic Axial Rating | 19.8 kN | 4455 lbf |
| Dynamic Radial Rating | 13.6 kN | 3060 lbf |
| Gear Ratio | 62:1 | — |
| Precision | ≤ 0.17° | — |
| Approx. Weight | 18 kg | — |
Technische Dokumente anfordern
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
