선외 유압 워퍼 LD50-173 LD50-173

1 / 2

전동 유압 액추에이터

선외 유압 워퍼 LD50-173 LD50-173

선외 유압 워퍼 LD50-173 LD50-173 is supplied by Elerover as a 전동 유압 액추에이터 for OEM and industrial motion projects. Request OEM customization for voltage, stroke, feedback and connectors.

Manufactured and supplied by Elerover — 전동 유압 액추에이터 manufacturer and OEM partner for industrial, medical, furniture and solar motion systems.

주요 사양

10
Operating temperature
11
N.W/G.W/Packing size
No
Item
Request OEM Quote WhatsApp
  • Custom stroke
  • Custom voltage
  • Custom connector
  • OEM / private-label inquiry

제품 개요

No Item Data 1 Voltage DC12v/24v/48v 2 Power 300w 3 Telescopic stroke 173mm 4 Maximum lift 1.8T 5 Collision Protection Yes 6 Lifting speed 10-11mm/s 7 waterproof level IPX6 8 Noise level 75DB 9 Working condition oudoor 10 Operating temperature -30 degrees Celsius to 70 degrees Celsius 11 N.W/G.W/Packing size 5.8kg/6.1kg/61x20x13cm

주요 특징

  • Reliable Electric Hydraulic Actuator solution for OEM projects
  • Robust mechanical design for continuous duty
  • Flexible voltage and mounting options
  • Custom configurations available on request

기술 사양

1 Voltage
2 Power
3 Telescopic stroke
4 Maximum lift
5 Collision Protection
6 Lifting speed
7 waterproof level
8 Noise level
9 Working condition
10 Operating temperature
11 N.W/G.W/Packing size
No Item

적용 분야

  • 리프팅

추가 세부 정보

Electric Hydraulic Actuator

Outboard Hydraulic Warper LD50-173

No Item Data 1 Voltage DC12v/24v/48v 2 Power 300w 3 Telescopic stroke 173mm 4 Maximum lift 1.8T 5 Collision Protection Yes 6 Lifting speed 10-11mm/s 7 waterproof level IPX6 8 Noise level 75DB 9 Working condition oudoor 10 Operating temperature -30 degrees Celsius to 70 degrees Celsius 11 N.W/G.W/Packing size 5.8kg/6.1kg/61x20x13cm

Need a Custom Configuration?

Contact Elerover for voltage, stroke, speed, feedback, cable length and connector customization. Messages go to [email protected].

Installation Guidance

Mount on a rigid structure, avoid side load, and confirm electrical polarity before first motion. Protect cables from abrasion and leave service access for inspection.
