SLA08B vérin linéaire 7000N

Robust, High-Force, and Versatile for Industrial Applications
Our Waterproof Heavy Duty Linear Actuator is designed to deliver superior performance and reliability in demanding industrial environments. With built-in limit switches, clutch double protection, and optional Hall feedback signal devices, this actuator is ideal for applications requiring high load output and precision.

Key Features
High-Force Performance
Micro DC Permanent Magnet Motor: Equipped with a micro DC permanent magnet motor, this actuator is compact, waterproof, and easy to install.
Customizable Stroke Length and Load Capacity: Offers a maximum stroke length of 1000mm and load capacities ranging from 1000N to 4000N. Other strokes and loads can be customized to meet specific requirements.
High Speed: Achieves a maximum working speed of 28.5mm/s.
Advanced Protection and Feedback
Built-in Limit Switch and Clutch Double Protection: Ensures safe and efficient operation by automatically stopping the actuator and protecting it from damage.
Signal Feedback Options: Supports Hall sensor and potentiometer for precise control and monitoring.
Metal Gear Construction: Provides stable quality and long service life.
Versatile and Easy to Use
Automatic Direction Change: Capable of automatically stopping and changing direction by reversing the polarity of the applied voltage.
Wide Application Range: Suitable for use in robotic vehicles, automatic guidance vehicles, campers, door openers, floor cleaning equipment, lawn mowers, snow plows, boats, solar tracker systems, wheelchairs, harvesting machines, construction machines, and more.

Specifications
Model: SLA08B
Input Voltage: 12V/24V/36V/48V DC
Stroke Length: 50/100/150/200/250/300/350/400/450/500/550/600mm (optional and customizable)
Load Capacity: 1000N/2000N/2500N/3000N/3500N/4000N (optional and customizable)
Max. Dynamic Load: 4000N
Travel Speed: 4.0 to 28.5mm/s (full load), 5.5 to 35.0mm/s (no-load)
Limit Switch: Integrated
Duty Cycle: 25% (4 minutes continuous moving)
IP Rating: IP65
Operating Temperature: -40°C to +65°C
Signal Feedback: Hall sensor, potentiometer (optional)
Cable Length: 500mm (customizable)
Certification: CE
Weight: 1kg-8kg
Our Waterproof Heavy Duty Linear Actuator is built to withstand harsh environments while providing reliable, high-performance operation. Contact us today to learn more about how this actuator can enhance your industrial applications.

Incorporate our Waterproof Heavy Duty Linear Actuator into your projects for exceptional strength, durability, and versatility in demanding industrial settings.
